Linear Washing Machine filled for water washing RF-8P/10P
It can complete the disinfection, hot and cold cleaning and drying of glass bottles and PET plastic cans.
The utility model has the advantages of convenient operation and simple maintenance, and the change of bottle type only needs simple adjustment without changing parts. It is an ideal equipment for modern canned beverage and condiment production enterprises. It is an ideal cleaning machine for food, pharmaceutical, daily chemical and other industries.
Product description of bottle washer
It is mainly composed of bottle holding belt, conveyor belt and two water and two gas cleaning structure, which can be used in supporting the filling line or washing bottles separately. The bottles are sent to the conveyor belt through the bottle holding belt, turned over by the bottle holding device into the cleaning system, pressurized with a sanitary pump, filled with water for the water washing process, and the spray pipe stem is inserted into the bottle to flush air to complete the water washing and gas washing process, The machine has the characteristics of convenient replacement of product model and high cleanliness of bottle washing. It is suitable for containers with different shapes.
Ideal cleaning machine
It can complete the disinfection, hot and cold cleaning and drying of glass bottles and PET plastic cans. The utility model has the advantages of convenient operation and simple maintenance, and the change of bottle type only needs simple adjustment without changing parts. It is an ideal equipment for modern canned beverage and condiment production enterprises. It is an ideal cleaning machine for food, pharmaceutical, daily chemical and other industries.
Technical parameters
|
Model |
RF-8P |
RF-10P |
|
Bottle Washing Capacity |
1500-2000 bottles/h |
1800-2500 bottles/h |
|
Spray Pressure |
0.2-0.3mpa |
0.6-0.8mpa |
|
Power |
1.2kw |
2.5kw |
|
Dimension |
2000*1300*1900mm |
2000*1400*1900mm |
|
Weight |
400kg |
430kg |
