HRS-130 Fully Automatic Softgel Encapsulation Making Machine
The host is the core component of the entire production line, which packages the filling material (liquid or viscous suspension) into soft gel using gelatin film.
Micro lubrication system: oil tank, adjustable flow control valve.
Gelatin film coating: spray glue box (0.01mm), PID temperature control, temperature sensor (0.1℃)
Features
Since its launch, the product has been successfully supplied to customers in over 100 countries and regions worldwide, serving a wide range of sectors including industrial manufacturing, healthcare, and daily consumer goods. With its stable and reliable performance, superior technical advantages, and comprehensive after-sales service, the product has earned widespread praise and high recognition from customers both at home and abroad. Extensive real-world user feedback and long-term partnerships are a strong testament to its exceptional quality and proven reliability, making it a trusted and dependable choice you can rely on.
Configuration list
|
Mould |
Φ64x130mm |
|
Rolling mill speed |
0-6rpm stepless speed control |
|
Feed rate |
8×（0-1.5）ml |
|
Load accuracy |
<500mg ±2%; >500mg ±1% |
|
Power |
5KW AC380V 50Hz |
|
Outline dimension |
1170×680×1800mm |
|
Weight |
500kg |
Mechanical Images
Product video
