Customized nozzles plastic ampoule filling sealing machine
The customized nozzles plastic ampoule filling sealing machine efficiently fills and seals plastic ampoules with high precision, accommodating various nozzle specifications to meet specific production requirements. It streamlines the packaging process, ensuring consistent output and minimizing material waste in pharmaceutical and cosmetic manufacturing environments.
Description:
Oral liquid, liquid, pesticide, perfume, cosmetics and pulp food category, etc
Product features
1). It adopts PLC control and stepless frequency conversion speed regulation.
2). The working processes such as unwinding, plastic forming, filling, batch number printing, indentation, punching and cutting are completed automatically by the program.
3). It adopts human-machine interface device, which has simple operation.
4). The filling has no dripping, bubbling, and overflowing.
5). The parts contacting with medicine all adopt high quality stainless steel material, which meets with GMP standard.
6). The main penumatic and electrical components adopt imported brand.
7). It adopts self-control filling system of electronic peristaltic pump and mechanical filling, which have accurate metering with small error.
Main technical parameters
Max. forming depth | 12mm |
Punch frequency | 0-30times/min |
Packing material | PVC/PE，PET/PE（0.2-0.4）×140mm |
Filling volume | 1-50ml |
Toal power supply power | 7KW |
Voltage | 220-380V/50Hz |
Machine weight | 900Kg |
Overall dimension (L*W*H) | 2300*850*1400(mm) |
