Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine 1

Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine 2

Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine 3

Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine 4

Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine 5

Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine 6

Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine 7

Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine

Name: Z260 Model Blister Medical Capsule Bottle Horizontal Cartoning Machine
Uploaded: 2026-01-21T13:46:06+08:00
Description: Features No instruction manual will be picked up without product; no cardboard box will be picked up without instruction manual. The machine will idle without pushing products when there are no products or when product supply is insufficient. It will

The Z-260 full-automatic high-speed cartoning machine is a self-innovatively designed model based on the introduction of foreign advanced technology, and is manufactured in strict accordance with the "GMP" requirements of the pharmaceutical industry. It has high-efficiency and high-performance production capacity. The related technologies of manual folding and transmission, carton forming, and rear pushing mechanism have reached European and American standards; the concise design and the rear continuous pushing structure make operation and maintenance easier , The quarter-divided double planetary wheel rotates outward to open the box and has a two-time pre-forming device to ensure that the carton is fully expanded and formed.

Delivery date:

30 working days

Payment terms:

Guarantee period:

1 year

Inquiry

Write a Review

Features

No instruction manual will be picked up without product; no cardboard box will be picked up without instruction manual.

The machine will idle without pushing products when there are no products or when product supply is insufficient. It will automatically resume operation once product supply resumes. It will automatically stop if the product is not properly seated in the box.

The machine will automatically stop if there are no cardboard boxes or if there are multiple consecutive instances of no instruction manuals being picked up.

Features

The machine will stop and alarm if the compressed air or vacuum negative pressure is too low.

The rear pushing mechanism provides more space on the front of the machine, making operation and maintenance more convenient and user-friendly for operators.

Servo feeding system: The feeding device uses a swing tracking method for feeding; compared with similar fixed feeding devices on the market, it is faster and more accurate; it can feed one piece of material or multiple pieces of material into the material conveyor chain groove at a time.

Technical parameters

Project		Parameter
Maximum packing speed		260 boxes/minute
Carton	Quality requirements	250-350g/㎡【Depends on the size of the carton】
	Size range（L×W×H）	（70-180）mm×（35-80）mm×（14-50）mm
Instructions	Quality requirements	60-70g/㎡
	Unfolded size range（L×W）	（80-250）㎜×（90-170）㎜
	Folding range（L×W）	【1-4】fold
Compressed air	Work pressure	≥0.6mpa
	Air consumption	200-240L/min
Power supply		380V 50HZ
Total power		5kw
Dimensions（L×W×H）		4800㎜×1600㎜×1860㎜
Weight		About 3000kg
